Service Parts ID Codes

1GCHG39R721179975
155.0
DXNZ5Z
CG31705
AK5
AS5
A12
B38
B9G
C60
DE2
EVA
E2C
E23
E24
GAM
GT4
JB8
KC4
KD1
K34
K68
L32
MT1
NA4
NC1
N33
R6F
R8A
R9R
R9Z
SLL
TEJ
TFD
T98
UM7
UP8
U73
VG8
VK3
VP6
VXS
V14
V73
WEN
XHH
X88
YA7
YD3
TD5
TD6
YF5
THH
YK6
ZHH
ZQ3
ZW2
ZW9
ZX2
ZY1
1SA
50U
6XD
69G
69I
7XD
8E1
BC/CC
U8624
69G

Van Update, New floor & Insulation Started

Three-quarter inch foam base then three quarter inch thick rubber mats, for horse stalls, for the floor. It took three of them at 4 foot by 6 foot

Then I use the same three quarter inch thick styrofoam with a mylar side on the van walls and roof

This step alone seems to keep it about 10 degrees or more cooler inside the van

Next will put some 1 inch thick foam boards over the walls and roof what should give us an insulation value of R9

Stay tuned for more updates as we continue to upgrade the van

New Van Buying Trip

Headed up to Phoenix to check out vans on Craigslist and any used car lots that had Cargo Vans

Had about a dozen to choose from

Tomorrow… This is F-ing happening #VanLife #GunShowLoopholeTour @DailyGunShow @GunWebsites

A post shared by Gear Websites (@gearwebsites) on


Got a new van !! Much thanks to Jimmy @EarlyWatchAZ for spending an entire day on the road shuttling the cop car back to Tucson !! #TheAdventureContinues

https://www.instagram.com/p/BWhUMNlhAYg/


https://www.instagram.com/p/BWhUlqdhopY/

#TheAdventureContinues
#GunShowLoopholeTour
#VanLife



New Van VIN Decoded

2002 Chevrolet Express Cargo Van 3500

  • 155″ WB
  • VIN: 1GCHG39R721xxxxxx

General Information

MFR model code CG31705
Body type: Full-size Cargo Van
Pass Doors: 3
Alternative body: Full-size Cargo Van
Drivetrain: Rear Wheel Drive

Original Pricing

MSRP $25,869.20
Invoice $22,636.08
Destination Charge $715.00

Engine & Powertrain

Type 8 Cylinder Engine
Displacement L/CI 5.7/350
Fuel Type Gasoline Fuel
Horsepower 255.0 @ 4600
Fuel Economy 0.0 City / 0.0 Highway
Fuel Capacity 31.0 gal
Net Torque 330.0 @ 2800

Tech Specs

Manufactured By United States Chevrolet
Active Curb Weight – Front 2897 lbs 2897.0 min 2897.0 max
Curb Weight – Rear 2458 lbs 2458.0 min 2458.0 max
Suspension Type – Front Independent Coil
Suspension Type – Rear 2-Stage Multi-Leaf
Front Tire Size LT245/75R16E
Rear Tire Size LT245/75R16E
Brake ABS System 4-Wheel
Front Brake Rotor Diam x Thickness 12.5 x 1.26 in
Wheelbase 155 in 155.0 min 155.0 max
Ground Clearance, Front 8.7 in 8.7 min 8.7 max
Ground Clearance, Rear 8.5 in 8.5 min 8.5 max

Mechanical & Powertrain

5.7L (350) SFI V8 Vortec 5700 engine
Brake/transmission shift interlock
Rear wheel drive
600-CCA battery
9500# GVWR (4300 front/6084 rear), springs (4300 front/6084 rear), axles (4300 front/6084 rear)
Independent coil spring front suspension w/stabilizer bar
Two-stage multi-leaf spring rear suspension
Spare tire carrier located underneath rear floor, accessed from outside
(4) black plastic center caps
Variable assist pwr steering
Pwr front disc/rear drum brakes
31 gallon fuel tank
Stainless steel muffler/tailpipe

Safety

Brake/transmission shift interlock
Front side door guard beams

Interior

Molded front/rear full-width black vinyl floor covering
Gauges-inc: speedometer, odometer, trip odometer, voltmeter, engine temp, oil pressure, fuel level
Headlamps-on warning tone
Passlock theft deterrent system
(2) cup holders in dash
Covered pwr outlet
Color-keyed cloth front headliner to B-pillar
Color-keyed padded vinyl sunshades
(2) dome lamps w/defeat switch, door-actuated switches

Exterior

Front/rear gray-painted bumpers w/rear entry-assist step
Molded gray plastic grille
Single rectangular halogen sealed beam headlamps
Black foldaway mirrors w/adjustable glass (RH convex)
Solar-Ray tinted glass on all windows
Intermittent windshield wipers
Hinged swing-out rear cargo doors

Tech Specs

  • Vehicle Name Chevrolet Express Cargo Van
  • Body Style 3500 Cargo Van 155″ WB
  • Body Code ZW9
  • Drivetrain Rear Wheel Drive
  • Passenger Capacity 1, 2 1.0 min 2.0 max
  • Gross Axle Wt Rating – Front 4300 lbs 4300.0 min 4300.0 max
  • Gross Axle Wt Rating – Rear 6084 lbs 6084.0 min 6084.0 max
  • Curb Weight – Front 2897 lbs 2897.0 min 2897.0 max
  • Curb Weight – Rear 2458 lbs 2458.0 min 2458.0 max
  • Gross Vehicle Weight Rating Cap 9500 lbs 9500.0 min 9500.0 max
  • Gross Combined Wt Rating 13,500, 12,000 lbs
  • Dead Weight Hitch – Max Trailer Wt. 4000 lbs 4000.0 min 4000.0 max
  • Dead Weight Hitch – Max Tongue Wt. 400 lbs 400.0 min 400.0 max
  • Wt Distributing Hitch – Max Trailer Wt. 10000 lbs 10000.0 min 10000.0 max
  • Wt Distributing Hitch – Max Tongue Wt. 1000 lbs 1000.0 min 1000.0 max Fifth Wheel Hitch – Max Trailer Wt. N/A lbs
  • Fifth Wheel Hitch – Max Tongue Wt. N/A lbs
  • Engine Order Code L31
  • Engine Type Gas V8 Displacement 5.7L/350
  • Fuel System SFI SAE
  • Net Horsepower @ RPM 255 @ 4600 SAE
  • Net Torque @ RPM 330 @ 2800
  • Trans Order Code MT1
  • Trans Type 4 4.0 min 4.0 max
  • Trans Description Cont. HD Automatic w/OD
  • First Gear Ratio (:1) 2.48 2.48 min 2.48 max
  • Second Gear Ratio (:1) 1.48 1.48 min 1.48 max
  • Third Gear Ratio (:1) 1.00 1.0 min 1.0 max
  • Fourth Gear Ratio (:1) 0.75 0.75 min 0.75 max
  • Reverse Ratio (:1) 2.08 2.08 min 2.08 max
  • Cold Cranking Amps @ 0° F (Primary) 770, 600 600.0 min 770.0 max
  • Cold Cranking Amps @ 0° F (2nd) 770 600.0 min 770.0 max
  • Maximum Alternator Capacity (amps) 130, 105 105.0 min 130.0 max
  • Total Cooling System Capacity 11 qts 11.0 min 11.0 max
  • Engine Oil Cooler Yes
  • Frame Type Ladder
  • Suspension Type – Front Independent Coil
  • Suspension Type – Rear 2-Stage Multi-Leaf
  • Spring Capacity – Front 4300 lbs 4300.0 min 4300.0 max
  • Spring Capacity – Rear 6084 lbs 6084.0 min 6084.0 max
  • Axle Type – Front Independent
  • Axle Type – Rear Full-Floating
  • Axle Capacity – Front 4300 lbs 4300.0 min 4300.0 max
  • Axle Capacity – Rear 6084 lbs 6084.0 min 6084.0 max
  • Axle Ratio (:1) – Rear 4.10, 3.42, 3.73 3.42 min 4.1 max
  • Shock Absorber Diameter – Front 32 mm 32.0 min 32.0 max
  • Shock Absorber Diameter – Rear 32 mm 32.0 min 32.0 max
  • Stabilizer Bar Diameter – Front 1.18 in 1.18 min 1.18 max
  • Front Tire Order Code XHH
  • Rear Tire Order Code XHH
  • Spare Tire Order Code ZX9, XHH
  • Front Tire Size LT245/75R16E
  • Rear Tire Size LT245/75R16E
  • Spare Tire Size LT245/75R16E
  • Front Tire Capacity 2205 lbs 2205.0 min 2205.0 max
  • Rear Tire Capacity 3042 lbs 3042.0 min 3042.0 max
  • Spare Tire Capacity 3042 lbs 3042.0 min 3042.0 max
  • Revolutions/Mile @ 45 mph – Front 678 Rev/Mile 678.0 min 678.0 max
  • Revolutions/Mile @ 45 mph – Rear 678 Rev/Mile 678.0 min 678.0 max
  • Revolutions/Mile @ 45 mph – Spare 678 Rev/Mile 678.0 min 678.0 max
  • Front Wheel Size 16 x 6.5 in
  • Rear Wheel Size 16 x 6.5 in
  • Spare Wheel Size 16 x 6.5 in
  • Front Wheel Material Steel
  • Rear Wheel Material Steel
  • Spare Wheel Material Steel
  • Steering Type Power-Assisted
  • Steering Ratio (:1), On Center 17.2 17.2 min 17.2 max
  • Turning Diameter – Curb to Curb 53.5 ft 53.5 min 53.5 max
  • Brake Type Power
  • Brake ABS System 4-Wheel
  • Disc – Front (Yes or ) Yes
  • Front Brake Rotor Diam x Thickness 12.5 x 1.26 in
  • Drum – Rear (Yes or ) Yes
  • Rear Drum Diam x Width 13.0 x 3.50 in
  • Fuel Tank Capacity, Approx 31 gal 31.0 min 31.0 max
  • Fuel Tank Location LH Midship Inboard
  • Front Head Room 40.6 in 40.6 min 40.6 max
  • Front Leg Room 41.1 in 41.1 min 41.1 max
  • Front Shoulder Room 68.8 in 68.8 min 68.8 max
  • Front Hip Room 63.8 in 63.8 min 63.8 max
  • Wheelbase 155 in 155.0 min 155.0 max
  • Length, Overall w/rear bumper 238.7 in 238.7 min 238.7 max
  • Width, Max w/o mirrors 79.2 in 79.2 min 79.2 max
  • Height, Overall 82.5 in 82.5 min 82.5 max
  • Overhang, Front 33.8 in 33.8 min 33.8 max
  • Overhang, Rear w/bumper 49.9 in 49.9 min 49.9 max
  • Ground to Top of Load Floor 29.2 in 29.2 min 29.2 max
  • Ground Clearance, Front 8.7 in 8.7 min 8.7 max
  • Ground Clearance, Rear 8.5 in 8.5 min 8.5 max
  • Rear Door Type Dual Swing-out
  • Rear Door Opening Height 49.7 in 49.7 min 49.7 max
  • Rear Door Opening Width 56.9 in 56.9 min 56.9 max
  • Side Door Type Sliding, Swing-out
  • Side Door Opening Height 49.1 in 49.1 min 49.1 max
  • Side Door Opening Width 40.8, 46.7 in 40.8 min 46.7 max
  • Step Up Height – Front 18.2 in 18.2 min 18.2 max
  • Step Up Height – Side 19.6 in 19.6 min 19.6 max
  • Cargo Area Length @ Floor to Console 171.0 in 171.0 min 171.0 max
  • Cargo Area Length @ Floor to Seat 1 147.3 in 147.3 min 147.3 max
  • Cargo Area Width @ Beltline 75.5 in 75.5 min 75.5 max
  • Cargo Box Width @ Wheelhousings 50.7 in 50.7 min 50.7 max
  • Cargo Box (Area) Height 53.8 in 53.8 min 53.8 max
  • Cargo Volume 316.8 ft³ 316.8 min 316.8 max

Phoenix Gun Shop Tour

Phoenix Gun Shop Tour (250 Miles)
Nov 26, 2016

  • AJI Sporting Goods
    10444 E Apache Trail
    Apache Junction, AZ 85220
  • Stop N Shop Military Surplus
    300 Apache Trail #124
    Apache Junction, AZ 85120

Cutting Board Bakery



Phoenix Gun Shop Tour

Headed out on a road trip to phoenix at 209,995.5

307 miles round trip. But the van died 50 miles from home. Had to get a tow from AAA

Visited

Phoenix Area Gun Shops

Arrived back in Tucson at 210,302.2

Died on the side of the highway
